Pressure Gauges

FPGB_SG0_16100

Model FPGB_SG0_16100
FPGB_SG0_16100
FPGB_SG0_16100

Summary Card

FunctionPressure measurement
Gauge typeGlycerine-filled Bourdon pressure gauge
Scale range0-16 bar
Process connectionG 1/2 B male, lower mount
MaterialCase : Stainless Steel, Process connection : Copper Alloy, Window: : Polycarbon, Case filling :
Temperature range"Ambient: -20 to 60 °C Medium: -20 to 100 °C"
Max. working pressure0-16 bar
Accuracy classCl. 1.6
Design standardEN 837-1
Ingress protectionIP65
MediaGaseous and liquid media that are not highly viscous or crystallising and will not attack copper alloy parts
Find Distributor
Request Quote
Download Datasheet
  • View Drawing

Info

Use: Local pressure indication and monitoring
Avoid: Media that are highly viscous, crystallising or attack copper alloy parts

Why This Valve

Product Overview

The FIVC Pressure Gauge FPGB_SG016 is a glycerine-filled Stainless Steel bourdon gauge for harsher operating conditions. It is intended for installations with vibration or dynamic pressure loads, where pointer stability, readability, and longer service life are more critical than the lowest cost.

Technical Specifications

FunctionPressure measurement
Measuring principleBourdon tube
Connector locationLower mount
Design standardEN 837-1
Accuracy classCl. 1.6
Scale range0-16 bar
Process connection detailsG 1/2 B male, 22 mm flats
Pressure limitation"Steady: 3/4 x full scale value Fluctuating: 2/3 x full scale value Short time: Full-scale value"
Ingress protectionIP65
Leak tightnessLeakage rate: < 5∙10-3 mbar l/s
Temperature error"On deviation from the reference conditions at the measuring system: ≤ ±0.4 % per 10 °C [≤ ±0.4 % per 18 °F] of full scale value"

Materials

CaseStainless Steel
Process connectionCopper Alloy
Dial / pointerAluminium dial, black scale on white background
Window / movement"Window: Polycarbonate Movement: Copper Alloy"
Case fillingGlycerine

Field of Application

Temperature range"Ambient: -20 to 60 °C Medium: -20 to 100 °C"
Max. working pressure0–16 bar
MediaGaseous and liquid media that are not highly viscous or crystallizing and will not attack copper alloy parts

Key Features

Clear pressure readingProvides fast and easy local pressure reading for routine system checks.
Data-driven decision-makingRisk-prevention tool that helps detect deviations early, avoid costly downtime, and maintain stable system performance.
Easy installationLower-mount configuration supports straightforward installation in standard applications.
Broad size rangeAvailable in multiple nominal sizes to suit common installation preferences.
General-purpose serviceSuitable for compatible gaseous and liquid media in general-duty service.

Usage & Applications

Declaration

EN 1092-2

Full Technical Data

2D Drawing
2D Drawing
Download

Quick Dimensions

Full Technical Data

2D Drawing
2D Drawing
Download
Frequently Asked Questions
What type of pressure gauge is this? +
It is a Bourdon-type pressure gauge for local pressure indication. The dry versions cover standard-duty use, while the SG version is glycerine-filled for harsher operating conditions.
Does it read gauge pressure or absolute pressure? +
Gauge pressure. The dry-gauge datasheets state that the device is zero-referenced against ambient pressure and reads zero when disconnected from the equipment.
When should the glycerine-filled version be selected? +
Choose the FPGB_SG016 version where vibration, pulsation or higher dynamic pressure loads are present. The glycerine filling improves pointer stability and is better suited to rougher service conditions.
Can these gauges be used with any fluid or gas? +
No. The datasheets limit use to gaseous and liquid media that are not highly viscous or crystallising and that will not attack copper alloy parts.
Are all versions CE-marked? +
No. The FPGB_P010 and FPGB_P016 datasheets state PED 2014/68/EU Art. 4.3 SEP exemption from CE marking, while the FPGB_SG016 datasheet shows PED 2014/68/EU and CE marking.
