The FIVC Bimetal Thermometer is designed as a bimetal type to be installed in pipelines for temperature-measurement purposes. The device is delivered with thermowell fittings operating up to 6 bar.
This device is suitable for water.
Function and benefits
QUICK DATASHEET DOWNLOAD
Feature: Pressure-measurement
Nominal size:
Nominal size for DN 63: PS
Nominal size for DN 80, 100: SAN
Connection location: Back mount, centre
Working scale: Full scale value
Accuracy class: lndication accuracy class 2 EN 13190
Thermowell: ISO 228 in DN 15. Available in different lengths. Removable, friction fit.
Zero adjustment: At bottom of the stem
USP: Quick and accurate reading ensuring proper system operation and energy efficiency, as well as for identifying potential problems such as overheating, underheating, or freezing. Durable and reliable. Thermowell included.
Case: Plastic
Stem: Aluminium
Process connection: Thermowell in Copper Alloy
Pointer: Plastic
Dial: Plastic w/Pointer
Window: Plastic
Temperature range: -30 to 50 °C
Max. working pressure: 6 bar
Media: Water
Removable Brass thermowell with retainer screw Other scale range
Case in Steel (galvanized) or Aluminium
Slip-on bezel, nickelplated
Size, material, approval, pressure rate, etc. are available upon request.
