FEAPRO ELECTRIC ACTUATOR
On-Off and Modulating | 10 – 20,000 N·m | IP67 | 1 or 3-phase | ISO 5211 Compatible
The FIVC FEAPRO is a high-performance electric actuator designed for precise quarter-turn control of butterfly, ball, and plug valves. Built for the toughest environments, the FEAPRO series offers On-Off and Modulating control modes, torque output from 10 to 20,000 N·m, and flexible voltage options across single- and three-phase setups. With advanced feedback, diagnostic capabilities, and intuitive interface options, FEAPRO is ideal for smart building and industrial automation.
Function and benefits
In short terms
QUICK DATASHEET DOWNLOAD
FEAPRO Basic and Integral
QUICK DATASHEET DOWNLOAD
FEAPRO Intelligent
- On-Off and Modulating control modes
- Torque range: 10–20000 N·m
- IP67 ingress protection (IP68 optional on select models)
- Single- and Three-phase compatibility
- ISO 5211 mounting compatibility
- Moisture-proof heater and over-torque protection
- Optional LCD display and digital diagnostics (Intelligent models)
- Seamless manual override without clutch
MAIN FEATURES AND MATERIALS
TECHNICAL SPECIFICATIONS
Feature: Advanced 90° electric actuator with planetary gear technology
Control Type: On-Off / Modulating
Torque Range: 10–20000 N·m
Voltage:
- Single-phase: 24/110/220/230/240V AC (50/60 Hz)
- Three-phase: 220/240/380/400/460/480V AC (50/60 Hz)
- DC: 24V (±10%)
Ingress Protection: IP67 standard (IP68 optional for Basic and Integral models)
Duty Cycle: - On-Off: S2 – 15 min, max 600 starts/hour
- Modulating: S4 – 50%, up to 1200 starts/hour (optional)
Signal Input: - On-Off: Contact (5A@250VAC)
- Modulating: 4–20 mA, 0–10V, 2–10V (150–250 Ω impedance)
Signal Output: 4–20 mA, 0–10V, 2–10V (≤750 Ω)
Feedback Options: Position feedback, fault alarm, Modbus/HART (Intelligent models)
Manual Override: Integrated planetary gear design (no clutch required)
Position Indicator: 3D visual window or LCD (model dependent)
USP: Full-range automation with built-in protection, diagnostics, and remote access options.
MAIN MATERIALS
Body: Epoxy-coated die-cast aluminum alloy
Worm Wheel / Gear Train: Planetary gear system
Fasteners: Stainless steel (S304)
Motor: Class F motor with thermal protection (Class H optional)
FIELD OF APPLICATION
Suitable for critical installations in:
- HVAC and smart building control
- Water and wastewater management
- Process automation and industrial systems
- Renewable energy and critical infrastructure
Operating Conditions:
- Ambient Temperature: –25 °C to +70 °C
- Optional: Down to –40 °C or –60 °C
- Relative Humidity: ≤90% RH (at 25 °C)
- Vibration Resistance: JB/T8219 compliant
- Noise: ≤75 dB at 1 m
DECLARATION
This product is designed and manufactured in accordance with:
LVD 2014/35/EU – Low Voltage Directive
EMC 2014/30/EU – Electromagnetic Compatibility
