The FIVC D-Syphon is a trumpet-shaped (D-shaped) device designed to prevent instrument damage due to pulsations within the media.It works by diverting the flow of media through the trumpet-shaped section of the device, which causes the pressure to equalize and reduces the impact of pulsations on the instrument. This helps to prevent damage to instruments, such as pressure gauges, by reducing the potential for overpressure or other damage caused by the pulsations.
Overall, the D-Syphon is a useful device in applications where pulsations within the media can cause damage to instruments, helping to protect the equipment and ensure accurate measurements.
Function and benefits
QUICK DATASHEET DOWNLOAD
Feature: Functions as a cooling element for media.
Connection: Inlet and outlet as a male thread
Design: DIN 16282
USP: Protects pressure measuring instruments from pulsations. Reliable and cost-effective.
Body in Stainless Steel 1.4571 to be used for oils and grease-free for oxygen services.
Body in Monel
Other connection threads
Other versions available upon request.
The product has been inspected and tested in accordance with the Sound Engineering Practice SEP. Acc. to the European PED Directive N° 2014/68/EU, dated 15/05/2014, the produet is exempted from CE marking (Cf. Art. 4.3).
Size, material, approval, pressure rate, etc. are available upon request.
