FIVC TRIPLE DUTY VALVE

FTDVA_N16_214 – Ductile Iron body – PN 16 – Angle – EN 1092-2

The FIVC Triple Duty Valve is designed as a 3-in-1 valve to be installed in pipelines to provide multiple functionalities replacing a regulation valve, non-return valve, and an isolation valve.

Featuring a unique changeable body, this valve lets you switch between a straight form and an elbow configuration on-site, making it easy to re-design or adapt the system to meet new conditions, without the hassle of sourcing and installing a whole new valve.

This valve is suitable for Water, Oil, and Gas.

Function and benefits

In short terms

QUICK DATASHEET DOWNLOAD

LET'S TALK

MAIN FEATURES AND MATERIALS

TECHNICAL SPECIFICATIONS

Feature: Regulating, isolating, and preventing the return of pressurized fluid.
Model: Angle-type or straight-type
Drilling: EN 1092-2 PN 16
Pressure test standard: BS EN 12266-1
USP: Three-in-one: Functions as a silent check valve, regulating valve, and shut-off valve. Changeable body including straight- or elbow configuration. Integrated positioning indicator. Cost-efficient, small in size, and easy operation.

MAIN MATERIALS

Body: Ductile Iron
Bonnet: Ductile Iron
Disc: Grey Cast Iron+EPDM
Stem: Stainless Steel
Handwheel: Carbon Steel

FIELD OF APPLICATION

Temperature range: -20 to 120 °C
Max. working pressure: 16 bar
Media: Water, Oil, and Gas

DECLARATION

The product has been inspected and tested in accordance with the European PED Directive No. 2014/68/EU, dated 15/05/2014.
