FIVC BALL VALVE
FBA_H25_F142 – Nickel-plated Brass – PN 25 – Full Port – ISO 228-1
The FIVC Ball Valve is designed as a quarter-turn, full port valve for use in pipeline isolation.
This ball valve is suitable for water.
Function and benefits
In short terms
QUICK DATASHEET DOWNLOAD
- Excellent flow isolation
- Minimum friction loss
- Long lifespan
- Durable and reliable
- Cost- and maintenance efficient
LET’S TALK
MAIN FEATURES AND MATERIALS
TECHNICAL SPECIFICATIONS
Feature: Manual operated ON/OFF by handle rotation
Threading: ISO 228
USP: Excellent and easy shut-off. Durable. Long lifetime.
MAIN MATERIALS
Body: Brass CW617N
Bonnet: Brass CW617N
Stem: Brass CW617N
Ball: Brass C37700
Lever handle: Steel
Seat: PTFE
FIELD OF APPLICATION
Temperature range:
DN 15-50: -20 to 90° C
DN 65-100: -20 to 120° C
Max. working pressure:
DN 15-50: 25 bar
DN 65-100: 20 bar
Media: Water
DECLARATION
The product has been inspected and tested in accordance with the Sound Engineering Practice SEP. Acc. to the European PED Directive No 2014/68/EU, dated 15/05/2014, the product is exempted from CE marking (Cf. Art. 4.3).
RELATED DOCUMENTS
DOWNLOADS
RELATED PRODUCTS
Size, material, approval, pressure rate, etc. are available upon request.
