FIVC SILENT CHECK VALVE
FCH_C16_SC220 – PN 16 – Wafer – EN 1092-2
The FIVC Silent Check Valve is designed to be installed in pipelines to eliminate the return of pressurized fluid.
The check valve close silently with help of its preloaded spring and is mainly used in heating/cooling or sanitary circuits.
Function and benefits
In short terms
QUICK DATASHEET DOWNLOAD
- Excellent flow isolation
- WRAS-approved
- Minimum pressure loss
- Longer lifetime
- Slow operation; Prevents the water hammer phenomenon
MAIN FEATURES AND MATERIALS
TECHNICAL SPECIFICATIONS
Feature: Self-actuating
Flange: EN 1092-2 PN 16
Dimensions: Face-to-Face
USP: Silent device. Cost- and maintenance efficient. Prevents water hammer
MAIN MATERIALS
Body: Grey Cast Iron GG 25
Disc: Ductile Iron GGG 40 CuZn40Pb2
Spring: Stainless Steel
Seal: EPDM
Guiding stem: Copper Alloy CuZn40Pb2
FIELD OF APPLICATION
Temperature range: -10 to 120 °C
Max. working pressure: 16 bar
Media: Water
DECLARATION
The product has been inspected and tested in accordance with the European PED Directive No. 2014/68/EU, dated 15/05/2014, and is CE marked.
