FIVC GLOBE VALVE
FGL_O16_RS – Bronze – PN 16 – Rising Stem – ISO 228
FIVC Globe Valves are designed as spherical valves to be installed in pipelines for isolating and regulating purposes. They are primarily used to ensure dependable throttle and shutoff functions in throttling flow applications.
Benefits of using the globe valves include their shut-off as well as throttling capability.
The slow opening and closing operation require multiple turns of the handwheel, which prevents the occurrence of a water hammer.
This globe valve is suitable for water.
Benefits of using the globe valves include their shut-off as well as throttling capability.
The slow opening and closing operation require multiple turns of the handwheel, which prevents the occurrence of a water hammer.
This globe valve is suitable for water.
Function and benefits
In short terms
QUICK DATASHEET DOWNLOAD
- Excellent shut-off
- Slow operation; prevents water hammer incidents
- Cost-, maintenance-, and installation efficient
- Excellent throttling capability
MAIN FEATURES AND MATERIALS
TECHNICAL SPECIFICATIONS
Feature: Regulating and isolating. Up to 90° turn movement.
Model: U-Flanged
Drilling: ANSI 150
Shaft: SS AISI 420
Thread: UNC
Seat: Replaceable
Construction: Pinless
External operator: Gearbox
Standard: BS EN 593
Dimensions: Face-to-Face acc. to EN 558-1 (series 20)
Top flange acc. to ISO 5211/NFE 29-402
Tests: Hydraulic test acc. to 12266/ISO 5208
USP: Bubble-tight, cost-efficient, small size, light in weight, small driving torque, easy operation, and fast-acting.
MAIN MATERIALS
Body: Ductile Iron
Disc: Stainless Steel
Stem: Stainless Steel
Seat: Replaceable EPDM
Gearbox: Ductile Iron
Coating: Epoxy 120 microns
FIELD OF APPLICATION
Temperature range: -20 to 110° C
Max. working pressure: 16 bar
Media: Water
DECLARATION
The product has been inspected and tested in accordance with the European PED Directive No. 2014/68/EU, dated 15/05/2014, and is CE marked.
RELATED PRODUCTS
Size, material, approval, pressure rate, etc. are available upon request.
For the complete product overview please refer to Products
